---------- (Task #1) 168.95.1.0/24 ==> 168.95.1.1 ~ 168.95.1.254 255.255.255.0 192.192.154.0/26 ==> 192.192.154.1 ~ 192.192.154.62 255.255.255.192 192.192.148.0/24 ~ 192.192.159.0/24 ==> 192.192.148.0 255.255.252.0 192.192.152.0 255.255.248.0 [ISP] en conf t host ISP int f0/0 ip addr 168.95.1.254 255.255.255.0 no shut int s0/0 ip addr 192.192.154.62 255.255.255.192 clock rate 64000 no shut ip route 192.192.148.0 255.255.252.0 192.192.154.61 ip route 192.192.152.0 255.255.248.0 192.192.154.61 end [CC] en conf t host CC int s0/0 ip addr 192.192.154.61 255.255.255.192 clock rate 64000 no shut ip route 0.0.0.0 0.0.0.0 192.192.154.62 end [ISP-PC] IP: 168.95.1.1 NM: 255.255.255.0 GW: 168.95.1.254 [CC] ping 168.95.1.1 (OK) ---------- (Task #2) IM: 192.192.152.64/26 ==> 192.192.152.65 ~ 192.192.152.126 255.255.255.192 EMBA: 192.192.156.0/24 ==> 192.192.156.1 ~ 192.192.156.254 255.255.255.0 IM: 172.17.0.0/20 ==> 172.17.0.1 ~ 172.17.15.254 255.255.240.0 (DHCP) 172.17.0.1 ~ 172.17.7.255 (non-DHCP) 172.17.8.0 ~ 172.17.15.254 EMBA: 172.17.16.0/20 ==> 172.17.16.1 ~ 172.17.31.254 255.255.240.0 (DHCP) 172.17.16.1 ~ 172.17.23.255 (non-DHCP) 172.17.24.0 ~ 172.17.31.254 [CC] en conf t int f0/0 ip addr 192.192.152.126 255.255.255.192 no shut int f0/1 ip addr 172.17.15.254 255.255.240.0 no shut int f1/0 no shut int f1/0.2 encap dot1q 2 ip addr 192.192.156.254 255.255.255.0 int f1/0.3 encap dot1q 3 ip addr 172.17.31.254 255.255.240.0 ip dhcp pool IM network 172.17.0.0 255.255.240.0 default-router 172.17.15.254 ip dhcp pool EMBA network 172.17.16.0 255.255.240.0 default-router 172.17.31.254 ip dhcp excluded-address 172.17.8.0 172.17.15.254 ip dhcp excluded-address 172.17.24.0 172.17.31.254 end [EMBA] en conf t host EMBA int f0/1 switchport mode trunk int f0/2 switchport access vlan 2 int f0/3 switchport access vlan 3 int f0/4 switchport access vlan 2 end [IM-PC1] IP: 192.192.152.65 NM: 255.255.255.192 GW: 192.192.152.126 [IM-PC2] (DHCP) [EMBA-PC1] IP: 192.192.156.1 NM: 255.255.255.0 GW: 192.192.156.254 [EMBA-PC2] (DHCP) [TFTP] IP: 192.192.156.2 NM: 255.255.255.0 GW: 192.192.156.254 [IM-PC1][EMBA-PC1][TFTP] ping 168.95.1.1 (OK) [IM-PC2][EMBA-PC2] ping 192.192.154.61 (OK) ping 192.192.154.62 (FAIL) ---------- (Task #3) [CC] en conf t access-list 10 permit 172.16.0.0 0.15.255.255 ip nat pool CC 192.192.154.40 192.192.154.49 netmask 255.255.255.192 ip nat inside source list 10 pool CC overload int s0/0 ip nat outside int f0/1 ip nat inside int f1/0.3 ip nat inside end [IM-PC2][EMBA-PC2] ping 192.192.154.62 (OK) ---------- (Task #4) [IM] en conf t host IM int f0/3 spanning-tree portfast end [LAB] IP_ADDRESS=172.17.8.0 IP_SUBNET_MASK=255.255.240.0 DEFAULT_GATEWAY=172.17.15.254 TFTP_SERVER=192.192.156.2 TFTP_FILE=c2600-i-mz.122-28.bin tftpdnld (y) reset [LAB] en conf t host LAB config-register 0x2102 access-list 10 permit 192.168.1.0 0.0.0.255 ip nat inside source list 10 int f0/0 overload int f0/0 ip nat outside ip addr 172.17.8.0 255.255.240.0 no shut int f0/1 ip nat inside ip addr 192.168.1.254 255.255.255.0 no shut ip route 0.0.0.0 0.0.0.0 172.17.15.254 end [LAB-PC] ping 168.95.1.1 (OK) ---------- ---------- (Task #5) [CC] en conf t int s0/2 encap frame-relay no shut int s0/2.1 multipoint ip nat inside ip addr 172.16.1.254 255.255.255.0 frame-relay map ip 172.16.1.1 101 broadcast frame-relay map ip 172.16.1.2 102 broadcast int s0/2.2 point-to-point ip nat inside ip addr 172.16.2.254 255.255.255.0 frame-relay interface-dlci 103 router eigrp 1 no auto-summary network 172.16.1.254 0.0.0.0 network 172.16.2.254 0.0.0.0 redist static end [BR1] en conf t host BR1 int s0/0 encap frame-relay ip addr 172.16.1.1 255.255.255.0 frame-relay map ip 172.16.1.2 101 broadcast frame-relay map ip 172.16.1.254 101 broadcast no shut int f0/0 ip addr 172.18.15.254 255.255.240.0 no shut router eigrp 1 no auto-summary network 172.16.0.0 network 172.18.0.0 end [BR2] en conf t host BR2 int s0/0 encap frame-relay ip addr 172.16.1.2 255.255.255.0 frame-relay map ip 172.16.1.1 201 broadcast frame-relay map ip 172.16.1.254 201 broadcast no shut int f0/0 ip addr 172.18.31.254 255.255.240.0 no shut router eigrp 1 no auto-summary network 172.16.0.0 network 172.18.0.0 end [BR3] en conf t host BR3 int s0/0 encap frame-relay ip addr 172.16.2.1 255.255.255.0 frame-relay map ip 172.16.2.254 301 broadcast no shut int f0/0 ip addr 172.18.47.254 255.255.240.0 no shut router eigrp 1 no auto-summary network 172.16.0.0 network 172.18.0.0 end [BR1-PC] GW: 172.18.15.254 [BR2-PC] GW: 172.18.31.254
